MACHINE DETAILS :
TOS WHN 130 CNC HBM
SYNTECH CONTROLLER – 5 AXIS
X : 3500 MM Y : 2000 MM Z : 1200 MM W:800 MM
TABLE SIZE : 2200 X 1800 MM. SPINDLE DIA. : 130 MM
MACHINE DETAILS :
VERTICAL BORING MILL TVL CNV 2500/3250 MAX JOB TURNING DIA 3300MM HEIGHT OF JOB 2500MM CONTROLLER- FANUC21 iTB
CNC TAKANG MAKE VRETICAL BORING MILL VLD -2000
TABLE DIA. : Ø1600 MM., MAX DIA. OF JOB : Ø2200 MM MAX HEIGHT OF JOB :1400 MM
12 TOOL ATC
KENNAMETAL MAKE TURN MILL BORING MACHINE
CNC VBM WITH C AXIS (LIVE SPINDLE)TABLE DIA. : Ø1200 MM., MAX DIA. OF JOB : Ø1600 MM MAX HEIGHT OF JOB :1600 MM 12 TOOL ATC
MICROCUT BUFFALO MAKE 5 AXIS HORIZONTAL BORING AND FACING MILL = 2 Nos.
X – 2000MM , Y – 1600MM , W – 500 MM, Z – 2500MM SPINDLE DIA.- 110MM,CONTROLLER 18iIMB , SIMULTANEOUS 4 AXIS 28 ATC
MICROCUT BUFFALO MAKE 5 AXIS HORIZONTAL BORING AND FACING MILL = 2 Nos.
X – 2000MM , Y – 1600MM , W – 500 MM, Z – 2500MM SPINDLE DIA.- 110MM,CONTROLLER 18iIMB , SIMULTANEOUS 4 AXIS 28 ATC
MACHINE DETAILS :
CNC TURNING LATHE MACHINE WITH MILLING ATTACHMENT
CNC LATHE MACHINE
MACHINE DETAILS :
SEDIN RUSSIAN MAKE VTL
MAX DIA. OF JOB – Ø2500 MM
MAX HEIGHT OF JOB – 1600 MM WITH DEGREE TURNING FACILITY UP TO 45°
MACHINE DETAILS :
CMM
X : 900 MM, Y : 1500 MM, Z : 800 MM LEAST COUNT – 0.1MICRON
MACHINE DETAILS :
SPERONI TOOL PRESETTING & MEASURING SYSTEM MAGIS 600
Axis Travel:
-
Diameter X = 400 mm (-50 / +350)
-
Height Z = 600 mm
-
EDGE 2.0 Control Software
-
Thermal Alphanumeric Label Printer
-
Automatic Mechanical Clamping System – ISO 50
-
Automatic (CNC) Spindle Axis – Autofocus
MACHINE DETAILS :
RADIAL DRILL MAKE CSEPEL ARM LENGTH 3300MM DRILLING CAPACITY 120MM IN STEEL MODEL RFH 110/3300
